G Code List PDF

G Code List PDF Download for free using the direct download link given at the bottom of this article.

G-code (also known as RS-274) is the name of the most prevalent programming language for computer numerical control (CNC) in computer-aided design and manufacturing (CAD/CAM). G-code provides metric-based numeric control of CAM-controlled equipment such as CNC milling machines.

G-code is the simple programming language for CNC machines. It consists of lines of code that are organized in blocks. Each block controls one CNC machining operation, such as a cutting operation with a specific tool. Each line in a block is labeled with the letter N and a number.

G Code List PDF

G codeDescription
G00Rapid traverse
G01Linear interpolation
G02Circular interpolation CW
G03Circular interpolation CCW
G04Dwell
G09Exact stop
G10Programmable data input
G20Input in inch
G21Input in mm
G22Stored stroke check function on
G23Stored stroke check function off
G27Reference position return check
G28Return to reference position
G32Thread cutting
G40Tool nose radius compensation cancel
G41Tool nose radius compensation left
G42Tool nose radius compensation right
G70Finish machining cycle
G71Turning cycle
G72Facing cycle
G73Pattern repeating cycle
G74Peck drilling cycle
G75Grooving cycle
G76Threading cycle
G92Coordinate system setting or max. spindle speed setting
G94Feed Per Minute
G95Feed Per Revolution
G96Constant surface speed control
G97Constant surface speed control cancel

You can download the G Code List PDF using the link given below.

G Code List PDF - 2nd Page
G Code List PDF - PAGE 2
